Section 1 – Setup
The model 2351 Tracker Expansion Board allows you to expand the number of entry points that the
models 1803PC, 1815, 1817, 1818, 1833, 1835, 1837 and 1838 PC Programmable Entry Systems
can control up to a maximum of 16. One Tracker board is required for each entry point. Tracker
boards will interface with a variety of weigand devices including card readers, RF transmitters, digital
keypads, etc. Tracker will also report gate operator data from DKS intelligent gate operators that have
Gate Tracker outputs. In addition to these features, Tracker can also monitor the status of a door,
report door ajar and forced entry conditions, sound local alarms, activate a building alarm system,
and has request to exit inputs.
1.1 General Information
• Expands the control capability of selected DKS entry systems to allow control for up to 16
entry points.
• Provides power and inputs for almost any 26-bit weigand device. May power two readers in
parallel if required. For example: an entry and exit card reader on a single door.
• Can be used to provide a variety of door monitoring functions, such as sounding an alarm, or
activating a building alarm system when the door is forced or held open.
• Provides a request to exit input.
• Provides three relay outputs to control the door (or gate), alarm system activation, and local
alarm activation.
• Hold Open Feature unlocks individual doors (or holds open individual gates) when
commanded from the entry system software.
• Monitors transactions from DKS intelligent gate operators. Can monitor slide or swing gate
operators and the parking gate operator in PAMS type applications.
To utilize the full capability of the Tracker expansion board(s), the DoorKing Remote Account
Manager for Windows software, V 5.3 or higher is required to be installed on the user supplied PC.
The chart below is to assist you in determining if you have the proper access equipment and gate
operators to utilize the full capability of the Tracker expansion board.
Access Control Systems
Model Control Board Max Tracker
Boards
Hold Open
Feature
1815, 1817,
1818
1852 through
1857
8 for 1815, 1817
16 for 1818
No
1815, 1817,
1818
1840, 1841,
1842 REV A, B
8 for 1815, 1817
16 for 1818
No
1815, 1817,
1818
1840, 1841,
1842 REV C
16 No
1815, 1817,
1818
1840, 1841,
1842 REV D, E
16 Yes
1803PC 1844 REV A 16 Yes
1833, 1835,
1837, 1838
183x
Series
16 Yes
Gate Operators
Model Control
Board
1601, 1602, 1603 1601 REV Q
and higher
1150, 9200, 9300 4402
9310 4403
9210, 9220, 9230
9530
4404
6500 4405
601, 602, 605,
610, 615, 620,
625, 630
4501 REV R
and higher
6050, 6100, 6300 4502
1100, 910, 915,
920
4601 REV J
and higher
9100, 9150 4602
2351-065-G-12-07 Page 7
