9050-065-P-9-11
30
NC
NO
4702-010
12
11
1
2
3
4
5
6
10
9
8
7
6
5
4
3
2
1
C
NO
UL 325
Terminal
Open Photo
Close Photo
Open Edge
NC
NO
4702-010
12
11
1
2
3
4
5
6
10
9
8
7
6
5
4
3
2
1
C
NO
UL 325
Terminal
Open Photo
Close Photo
Open Edge
Interconnection Cable
Sold separately from DoorKing.
5 wires used (8 - 18 AWG wires total).
External Loop Detectors
DKS plug-in loop detectors CANNOT be used
in this primary / secondary arrangement. Use
external detectors that have a normally open
(N.O.) relay contact. Loop detectors must use
a separate power source.
Reverse loop lead-in
wires are wired in series.
Automatic
Exit Loop
Reverse
Loop
Reverse
Loop
Secondary Operator
Primary Operator
24 Volt Power 250 mamp. max.
Relay
Com
#8 Yellow
#8 Yellow
#9 Brown
#9 Brown
#12 Orange
#12 Orange
Green to
primary
operator
chassis
ground.
Green to
secondary
operator
chassis
ground.
Purple to Close Photo #2
Blue Blue Red Red Gray Gray
Purple to Close Photo #2
Com
N.O.
N.O.
3-Wire Receiver
Bi-Parting Gates Secondary Entrapment Protection Devices
To Close Photo #2 To Close Photo #2
To Close Photo #2
To Open Edge #3
To Open Edge #3
To Common #12 Main Terminal
To Common #12 Main Terminal
To Open Photo #1
To Open Photo #1
Fence
Gate
Opening Non-Contact Sensor
Closing Non-Contact Sensor
Opening Contact Sensor
Opening Contact Sensor
Opening Non-Contact Sensor
Fence
4-wire receiver wiring, see page 29.
Gate
Note: Connect other opening
devices to primary main
terminal #8 and #12 as required
(See page 29). They must use a
separate power source if power
is required.
• Requires AC power to each operator.
• Both operator DIP-switches must to be set.
• Connect all control devices, auxiliary devices
and loops to the primary operator only.
• Separate power source for
photo sensors (See page 24).
5.3 Bi-Parting Gates Wiring - Dual Gate Operators
Secondary
Operator
Primary
Operator
Filler Post if necessary (See page 8 for more information).Filler Post if necessary (See page 8 for more information).
