Questions and Answers:

J
Joshua TaylorAug 19, 2025
Why is the loop detector LED always on for my DKS 1601 Gate Opener?
- B
  Brenda FloresAug 19, 2025
  If the loop detector LED is continuously illuminated, try the following: * Activate the reset switch on the loop detector. * Decrease the loop detector sensitivity. * Check the loop wire for resistance to ground with a meg-ohm meter, ensuring it reads 100 meg-ohms or higher. Replace the loop wire if it's less than 50 meg-ohms. * Ensure the loop lead-in wire is twisted at least six turns per foot. * Solder all loop connections. * If the issue persists, consider replacing the loop detector.
J
Jessica PorterAug 22, 2025
How to fix a DKS Gate Opener arm that goes up but not down?
- E
  Elizabeth HaleAug 22, 2025
  If your DKS Gate Opener arm rotates up but not down, consider the following: * Check the LEDs on terminals 6, 7, and 9. If any are on, it indicates a shorted input holding the arm up. * Examine the LEDs on the loop detectors. If any are on, a loop or loop detector problem might be holding the arm up. * If the auto timer isn't used (SW1, switch 7 off), ensure SW1, switch 6 is on to activate terminal 6 for downward rotation. * Verify that SW1, switch 4 is on, so that terminal 8 activation and deactivation will rotate the arm down.
T
Terry CoxAug 25, 2025
What to do if the loop detector LED never turns on in my DKS 1601?
- C
  craigtaylorAug 25, 2025
  If the loop detector LED on your DKS Gate Opener never activates, try these steps: * Increase the loop detector sensitivity. * Check the continuity of the loop wire; it should be 0 ohms. If not, inspect all connections and replace the loop wire if needed. * Move the loop detector board to the other loop detector port on the control board to check loop operation. Replace the loop board if it still fails. * If the loop detector works in the other port, replace the control board.
B
Bethany GibsonAug 26, 2025
How to troubleshoot a DKS 1601 with no power LED?
- N
  Nicole HowardAug 26, 2025
  If your DKS Gate Opener operator won't run and the power LED on the control board is off: * Ensure the AC power switch is turned on. * Check for 117 VAC with a voltmeter at control board terminals 1 and 2. If there's no voltage, inspect the power supply to the operator or the terminal strip. If the voltage is OK, replace the control board.
P
pattersoncarlosAug 28, 2025
What to do if my DKS 1601 won't run but the power LED is on?
- D
  Derrick NicholsonAug 28, 2025
  If the DKS Gate Opener operator won't run, but the power LED on the control board is on: * Momentarily jumper terminal 6 to terminal 14. If the input LED doesn't illuminate, check the terminal strip or replace the control board. * Momentarily jumper terminal 2 to terminal 3 (Caution – High Voltage). The motor should run. * Momentarily jumper terminal 2 to terminal 4 (Caution – High Voltage). The motor should run in the opposite direction. * If the motor doesn't run in either or both steps, there may be an issue with the motor, motor capacitor, or wiring to the motor.
R
Rhonda MoralesAug 30, 2025
Why won't the down input rotate the DKS 1601 arm down?
- J
  John GomezAug 30, 2025
  If the down input or down loop will not rotate the arm to the down position on your DKS Gate Opener: * Ensure that SW1, switch 4 is in the ON position. * The down input must be activated and then deactivated to cause the arm to rotate down.
M
Matthew ThompsonSep 1, 2025
What to check if the DKS Gate Opener battery backup doesn't work?
- J
  Jennifer RichardsSep 1, 2025
  If the battery back-up system on your DKS Gate Opener fails to raise the arm during a power outage: * Verify that the 2340-010 battery back-up control board switch settings are configured as described in section 2.x. * Ensure the back-up system toggle switch is in the ON position. * Check the batteries for proper voltage and replace them if necessary. * If the problem persists, replace the 2340-010 control board.
B
Brandon CastroSep 3, 2025
Why DKS 1601 loop detector LED is on continuously?
- S
  Shawn MoralesSep 3, 2025
  If the loop detector LED stays on, try these steps: * Activate the reset switch on the loop detector. * Decrease the loop detector sensitivity. * Check the loop wire for resistance to ground using a meg-ohm meter. It should read 100 meg-ohms or higher. Replace the loop wire if it's less than 50 meg-ohms. * Ensure the loop lead-in wire is twisted at least six turns per foot. * Make sure all loop connections are soldered. * If none of the above steps work, replace the loop detector.
V
Valerie GuzmanSep 5, 2025
What to do if DKS 1601 operator will not run and power LED is OFF?
- R
  Ryan LawrenceSep 6, 2025
  If your DKS gate operator isn't running and the power LED is off: * First, check that the power to the operator is turned on. * Next, use a voltmeter to check for 117 VAC at control board terminals 1 and 2. If the voltage measures 0, check the power supply to the operator or the terminal strip. * If the voltage measures OK, the control board may need to be replaced.
J
john82Sep 8, 2025
What to do if DKS 1601 operator will not run but power LED is ON?
- T
  Tyler SchmidtSep 8, 2025
  If the DKS gate operator won't run but the power LED is on: * Momentarily jumper terminal 6 to terminal 14. If the input LED does not come on, check the terminal strip or replace the control board. * Momentarily jumper terminal 2 to terminal 3 (Caution – High Voltage). The motor should run. * Momentarily jumper terminal 2 to terminal 4 (Caution – High Voltage). The motor should run in the opposite direction. * If the motor doesn't run in either or both of the above steps, there may be a problem with the motor, motor capacitor, or wiring to the motor.
