1.2 MOUNTING POSITION
The 1601 and 1602 operators are designed to be mounted in either a left hand or right hand mounting
position. Care should be taken to be sure that the access door to the operator is opposite the traffic
lane.
Door
Left Hand Mount
Door
Right Hand Mount
Access
Control
Access
Control
10 Ft
Minimum
Traffic Traffic
Speed
Bump
Speed
Bump
Figure 2
