DKS 9100 User Manual (English)

Other manuals for DKS 9100

Questions and Answers:

E
Eric JonesAug 14, 2025
How to fix DKS Gate Opener when operator will not run and power LED is OFF?
- L
  Lawrence RileyAug 14, 2025
  If the DKS Gate Opener's power LED is off and the operator won't run, first ensure that AC power to the operator is turned on. If it still doesn't work, the transformer might be overheated; turn the power off, let the board cool down for a few minutes, and then try again. Also, check for low 115 VAC power and any low voltage shorts. Finally, check for 115 VAC at the high voltage terminal. If the voltage measures 0, inspect the incoming power wires or consider replacing the circuit board.
A
Amy BrayAug 17, 2025
What to do if DKS 9100 opens but will not close?
- J
  John GarciaAug 17, 2025
  If your DKS Gate Opener opens but won't close, check the input LEDs; any that are ON indicate a problem with a keying device. Also, inspect the secondary safety devices; if any are activated, that indicates a problem with the safety device. Check the loop detectors as well, because if any are activated, this can hold the gate open, signaling a problem with the loop detector or ground loop. The operator might be in a 'soft shutdown' state, so try activating any keying device to see if the operator returns to normal operation. If you want the gate to close automatically, make sure SW 1, switch 2 is ON and set the timer open from 1 to 23 seconds.
E
Elizabeth Villarreal MDAug 21, 2025
Why DKS 9100 Gate Opener won't run when power LED is ON?
- J
  James CooperAug 21, 2025
  If the DKS Gate Opener's power LED is ON but the operator won't run, and if a photo-cell is being used, make sure its beam isn't blocked. Check that the chain isn't too tight, as this can cause the operator to stall. To check the motor, turn the power switch OFF and remove the circuit board. Place a jumper wire from the 117 VAC SWITCHED terminal to the BLUE wire on the 8 pin POWER connector on the control board. If the motor runs in both steps above, replace the control board. If the motor does not run, or runs in only one direction, the problem can be a bad motor, motor capacitor, motor resistors, wire connections from the control board to the motor or a bad control board.
W
wilsontinaAug 25, 2025
Why does DKS 9100 Gate Opener start to close, then reverses to open?
- D
  danasheppardAug 25, 2025
  If your DKS Gate Opener starts to close and then reverses to open, check that the clutch is adjusted properly and is not slipping. Re-adjust the reverse sensitivity. Disconnect the gate from the gate operator and verify that it slides freely without any binding. Check the loop detector LEDs and input LEDs. Also, check the Magnetic Sensor LEDs on the circuit board.
T
tara12Aug 27, 2025
What to do if DKS 9100 Gate Opener opens a short distance, then stops and reverses?
- M
  Misty HillAug 27, 2025
  If the DKS Gate Opener opens a short distance, then stops and reverses, check that the clutch is adjusted properly and is not slipping. Disconnect the gate from the gate operator and ensure it slides freely without any binding. Re-adjust the reverse sensitivity. Make sure the magnetic pickup transistors on the control board aren't obstructed by excess wires and are within 1/8 inch of the clear plastic protective cover.
B
Brandi JohnsonAug 31, 2025
Why does DKS 9100 Gate Opener close then re-opens?
- D
  dsmithAug 31, 2025
  If the DKS Gate Opener closes and then re-opens, check for any input or loop detector LEDs that are ON. Ensure that the operator is running in the proper direction. Check the SELF-TEST DIP switch setting.
J
Jessica FisherSep 3, 2025
What to do if DKS 9100 closes but will not open?
- H
  Heather RoblesSep 3, 2025
  If the DKS Gate Opener closes but won't open, the operator may be in a 'soft shutdown.' Check input LEDs. Ensure the operator is running in the proper direction. Check that each LED on the control board lights when the keying device connected to that terminal is activated. If an LED doesn't light, momentarily place a jumper wire from terminal 1 to the input terminal being checked.
H
hensonbrendaSep 6, 2025
How to reset DKS 9100 Gate Opener alarm when operator will not run?
- E
  Erika PowellSep 7, 2025
  If the alarm is sounding and the DKS Gate Opener won't run, the operator is in a 'hard shutdown' condition. You must push the reset button to return the operator to normal operation.
R
Ryan SmithSep 9, 2025
What does it mean when DKS 9100 Gate Opener alarm chirps every 5 seconds and operator will not run?
- G
  gabriellewilliamsSep 10, 2025
  If the alarm chirps once every 5 seconds and the DKS Gate Opener won't run, the operator has been in a 'hard shutdown' condition for more than 5 minutes. You must push the reset button to return the operator to normal operation.

DKS 9100 Specifications

General

Brand	DKS
Model	9100
Category	Gate Opener
Language	English

Summary

General Information

Important Notices and Safety

Crucial safety warnings, operational hazards, and general user responsibilities for gate systems.

Restrictions and Entrapment Protection

Outlines installation requirements, warnings, and details on entrapment sensing systems for safe operation.

Glossary of Terms

Provides definitions for technical terms used within the gate operator manual.

Section 1 – Installation

1.1 Specifications

Key technical specifications for the Model 9100 gate operator, including horsepower, voltage, and dimensions.

1.2 Mounting Positions

Describes various mounting configurations for the gate operator, including front, rear, and center pad/post options.

1.3 Mounting Options

Details pad and post mounting procedures, including concrete preparation, conduit setup, and anchor bolts.

1.4 Operator Installation

Step-by-step guide for physically attaching the gate operator to the mounting surface, ensuring proper alignment.

1.5 Chain Installation

Instructions for routing, tensioning, and securing the drive chain for different mounting configurations.

1.6 Warning Sign Installation

Guidance on properly positioning warning signs to alert users of potential hazards.

Section 2 – Wiring

2.1 High Voltage Connections

Procedures for connecting the operator to the main power supply, including wire gauge selection.

2.2 Control Wiring

Details on wiring various control devices to the operator's terminal strip.

2.3 Secondary Entrapment Protection Device Wiring

Wiring diagrams and procedures for installing non-contact and contact sensors for safety.

2.4 Loop Detector Wiring

Instructions for connecting loop detectors to prevent the gate from closing on vehicles.

2.5 Gate Tracker™ Connections

Steps for connecting the gate operator to an access control system.

2.6 Auxiliary Devices

Wiring instructions for optional auxiliary devices like alarm reset buttons and stop switches.

2.7 Master / Slave Wiring

Configuration guide for connecting two gate operators in a master/slave setup.

2.8 Terminal Identification and Description

Comprehensive explanation of main and auxiliary terminal functions and their connections.

Section 3 – Adjustments

3.1 Circuit Board Adjustments

Guide to setting DIP switches and other controls on the circuit board for configuring operator functions.

3.2 Switch Settings

Detailed explanation of SW1 and SW2 switch settings to program the operator's behavior and features.

3.3 Automatic Limit Adjustment

Procedure to automatically set the gate's open and close limits based on physical stops.

3.4 Inherent Reverse Adjustment

Instructions for adjusting the sensitivity of the entrapment system and the mechanical clutch.

Section 4 – Operating Instructions

4.1 Power and Reset Switches

Identifies and explains the function of the main power toggle switch and the operator reset button.

4.2 Shutdown Conditions

Describes soft and hard shutdown states caused by entrapment and the procedures for resetting the operator.

4.3 Manual / Emergency Gate Operation

Outlines methods for manual gate operation during power failures, including Fail-Safe and Fail-Secure systems.

Section 5 – Maintenance and Troubleshooting

5.1 Maintenance

Provides a scheduled maintenance checklist for the gate operator, covering belts, chains, and safety devices.

5.2 Troubleshooting

Offers guidance on diagnosing and resolving common issues with the gate operator, including symptoms and solutions.

5.3 Accessories

Lists compatible accessory items for the model 9100 slide gate operator.
