DLE DLE-20RA - Replacement Parts

21
Replacement Parts
Key
No.
Optional Parts (not shown)
Stock
No.
Mfg Stock
No. Description
1 DLEG2301 20-V1 Propeller Washer
2 DLEG2302 20-V2 Propeller Drive Nut
3 DLEG2303 20-V3 Propeller Drive Hub
4 DLEG2304 20-V4 Bearing Front
5 DLEG2305 20-V5 Crankcase
6 DLEG2306 20-V6 Connecting Rod
7 DLEG2307 20-V7 Bearing Rear
8 DLEG2308 20-V8 Woodruff Key
9 DLEG2309 20-V9 Crankshaft
10
12
16 DLEG2310 20-V10 Gasket Set
24
30
11 DLEG2311 20-V11 Carburetor Heat Block
13
14 DLEG2313 20-V13 Reed Valve Assembly
15
14 DLEG2314 20-V14 Reed Valve Petals (2)
15 DLEG2315 20-V15 Reed Valve Plates (2)
17 DLEG2317 20-V17 Carburetor Complete
18 DLEG2318 20-V18 Back Plate O-Ring
19 DLEG2319 20-V19 Needle Bearing
20
21 DLEG2320 20-V20 Piston w/Pin & Retainer
22
21 DLEG2321 20-V21 Piston Pin
22 DLEG2322 20-V22 Piston Pin Retainers (2)
23 DLEG2323 20-V23 Piston Ring
24
25
DLEG2325 20-V25 Cylinder with Gasket
26 DLEG2326 20-V26 Spark Plug
27 DLEG2327 20-V27 Spark Plug Cap
27
28 DLEG2328 20-V28 Electronic Ignition
29
29 DLEG2329 20-V29 Ignition Sensor
30
31
32
DLEG2331 20-V31 Muffler
33
32 DLEG2332 20-V32 Exhaust Clamp
33 DLEG2333 20-V33 Exhaust Tube
34 DLEG2334 20-V34 Screw Set
DLEG5525 Onboard Digital Tachometer
DLEG9205 Opto Gas Engine Kill Switch V2.0
