3.1.4.3 Rotor adjustment for standard execution
The standard executions have the following axial and radial clearances.
Type
Body
end covers
material
Rotor
material
Size valve
Clearance
axial and radial
AL-BL
Cast iron
Mild Steel
150 - 350
0,12 - 0,17 mm
400 - 500
0,15 - 0,2 mm
Stainless steel
150 - 350
0,12 - 0,17 mm
400 - 500
0,15 - 0,2 mm
Stainless steel
Stainless steel
150 - 250
0,12 - 0,17 mm
300 - 350
0,15 - 0,2 mm
400 - 500
0,2 - 0,25 mm
AXL-AML
BXL
Cast iron
Mild Steel
150 - 400
0,12 - 0,17 mm
Stainless steel
150 - 400
0,12 - 0,17 mm
Stainless steel
Stainless steel
150 - 300
0,12 - 0,17 mm
350 - 400
0,15 - 0,2 mm
BXXL
Stainless steel
Stainless steel
350
0,12 - 0,17 mm
Special clearances are to be set with product temperatures of 50C
and higher, according to special instructions, depending on size and
material of the valve.
Product characteristics may influence the clearance. In case of any
doubts please contact sales department.
