Installer Options Menu
The 7000 Series keypads also contain Keypad Option and Keypad Diagnostic programs that allow installers and
service technicians to congure and test keypad operation.
Access the Installer Menu
Access the Installer Options Menu through the User Options function. Hold down the <— and CMD keys for two
seconds to display the SET BRIGHTNESS option. Immediately enter the code 3577 (INST) and press CMD. The display
changes to KPD OPT (keypad options) KPD DIAG (keypad diagnostics) and STOP.
The keypad options menu allows you to set the keypad address, select supervised or unsupervised mode, change the
default keypad message, enable any or all 2-button Panic keys, congure Soft-Shunt, Request-to-Exit, and 4-digit
entry cards.
Note: All programming options display on all keypads, however, actual operation for some programming options is
restricted to the listed keypads.
Programming Keypad Options
KPD KPD
OPT DIAG STOP
Keypad Options (KPD OPT)
To program keypad options, press the left Select key under KPD OPT. The display
changes to CURRENT KEYPAD ADDRESS: # #.
CURRENT KEYPAD
ADDRESS: 01
Keypad Address
Set the keypad address from 01 to 05 with the XRSuper6 and XR20, from 01 to 08
with the XR40, XR200, XR2400F, and 01 to 16 with the XR200-485, XR500 Series, and
XR2500F. The factory default address is set at 01. To change the current address, press
any Select key and then enter the new address using the appropriate number keys on
the keyboard. It is not necessary to enter a leading zero for addresses 01 to 09.
KEYPAD MODE:
*SUP UNSUP
Keypad Mode
Congure the keypad for either supervised or unsupervised operation. Keypads with
zones connected to them must be supervised. Supervised keypads cannot share
addresses with other keypads.
Unsupervised keypads can operate with other unsupervised keypads sharing the same
address. Zones cannot be used on unsupervised keypads. To change the current
setting, press the Select key under SUP or UNSUP. An asterisk appears next to the
selected option.
Note: Unsupervised addresses cannot be used when Device Fail Output has a
programmed value other than zero.
DEFAULT KEYPAD MSG:
Default Keypad Message
Enter a custom message of up to 16 characters to appear on the keypad display top line
whenever that line is not used for any other purpose. Press any Select key to clear the
current display and use the data entry keys to enter a new custom display.
ARM PANIC KEYS:
*PN *EM *F1
Arm Panic Keys
Use this option to congure the top row Select keys as 2-button Panic keys. To enable
or disable a Panic, press the Select key under the appropriate display: PN (Panic), EM
(Emergency), and FI (Fire). Once the panic is enabled, an asterisk displays next to the
description. Refer to the Panic Key Options section earlier in this document.
7/0 PANIC
ENABLE: NO YES
7/0 Panic
Use this option to congure the 7 and 0 keys as a 2-button Panic feature. To enable
the 7/0 Panic, select YES. To disable the option, select NO. Default is NO. To operate,
simply press and hold the 7 and 0 keys for one-half (1/2) second. Refer to the Panic
Key Options section earlier in this document.
ACTIVATE ZONE 2
SHUNT: NO YES
Zone 2 Shunt (7073 only)
Select YES to enable the Soft-Shunt™ option on zone 2 as described earlier in this
document. This zone provides the Soft-Shunt™ for door contacts. This zone must be
programmed into the panel.
