The Keypad Options menu allows you to set the keypad address, select
Supervised or Unsupervised mode, change the default keypad message,
selectively enable the 2-button Panic keys, Soft-Shunt, Request-to-Exit, and set
entry card options.
Note: All programming options display on all keypads, however, actual
operation for some programming options is restricted to the listed keypads.
Programming Keypad Options
KPD KPD
OPT DIAG STOP
Keypad Options (KPD OPT)
To program keypad options, press the left Select
key under KPD OPT. The display changes to
CURRENT KEYPAD ADDRESS: # #.
CURRENT KEYPAD
ADDRESS: 01
Keypad Address
Set the keypad address from 01 to 05 with the
XRSuper6 and XR20, from 01 to 08 with the XR40,
XR200, XR2400F, and 01 to 16 with the XR200-
485, XR500 Series, and XR2500F. The factory
default address is set at 01. To change the current
address, press any Select key and then enter the
new address using the appropriate number keys on
the keyboard. It is not necessary to enter a leading
zero for addresses 01 to 09.
KEYPAD MODE:
*SUP UNSUP
Keypad Mode
Congure the keypad for either Supervised or
Unsupervised operation. Keypads with zones
connected to them must be supervised. Supervised
keypads cannot share addresses with other
keypads.
Unsupervised keypads can operate with other
unsupervised keypads sharing the same address.
Zones cannot be used on unsupervised keypads. To
change the current setting, press the Select key
under SUP or UNSUP. An asterisk appears next to
the selected option.
Note: Unsupervised addresses cannot be used when
Device Fail Output has a programmed value other
than zero.
