Accessing Keypad Diagnostics
If necessary, refer to Access the Installer Menu earlier in this document.
KPD KPD
OPT DIAG STOP
Keypad Diagnostics (KPD DIAG)
The Keypad Diagnostic option allows you to
check the display segments, check the keyboard
backlighting, and test individual keys.
Press the Select key under KPD DIAG. The keypad
lights all display segments and illuminates the
keyboard in green. A few seconds later the keypad
turns the display off and illuminates the keyboard
in red. The keypad then alternates between these
two states for approximately two minutes. Press
COMMAND at any time to continue.
PRESS KEY TO
TEST
Test Individual Keys
The display changes to PRESS KEY TO TEST. This
option allows you to test each key on the keyboard
to ensure it is operating properly. Press and hold
each key for about two seconds. The key number
being held appears in the display. Verify the
correct number displays before testing the next
key.
Z1 OPEN Z2 OPEN
Z3 OPEN Z4 OPEN
Zone Test
(7063/7063A, 7073/7073A, 693/793 only)
This option allows the keypads to display the
current electrical status of the four protection
zones. The status is shown as OPEN, SHRT, or OKAY.
Note: The Zone Test displays on 7060 and 7063
keypads, but is not operational.
INPUT WIEGAND
Input Wiegand
(7063/7063A, 7073/7073A, 693/793 only)
This option tests the internal and external reader
input from proximity credentials. The display
shows OKAY each time a good proximity read is
received.
Exiting the Installer Options
When done, press the COMMAND key once to return to the Installer Options
screen. Press the Select key under STOP to exit the Installer Options function.
