Digital Monitoring Products, Inc | 7000 Series Installation and Programming Guide 18
Activate Zone 2 Bypass (7073/A, 7173 only)
Select YES to activate the zone 2 bypass operation.
Selecting NO allows standard zone operation on zone 2. The
default is NO.
Zone 2 Bypass Time (7073/A, 7173 only)
Enter the number of bypass seconds to elapse before the
bypass timer expires. Range is 20-250 seconds. Press any
select key to enter the number of seconds. Once the door
strike relay is activated, the user has five seconds to open
the door connected to zone 2. The zone is then bypassed for
the programmed time or until the contact restores to normal.
Ten seconds prior to the expiration of the bypass time, the
keypad beeps if the door is still open. If the door remains
open when the timer expires, a zone open/short is sent to
the panel for zone 2. Default is 40 seconds.
Relock on Zone 2 Fault? (7073/A, 7173 only)
Select NO to leave the relay on when zone 2 faults to an
open or short condition during bypass. Select YES to turn
the relay o when zone 2 faults open or short during bypass.
Default is NO.
ACTIVATE ZONE 2
BYPASS? NO
ZONE 2 BYPASS
TIME: 40
RELOCK ZONE 2
CHANGE: NO YES
