DMSI 10 - Specifications

www.dmsimfg.com
You can also nd the manual online at:
www.dmsimfg.com/StandAloneManual
OVERVIEW
SPECIFICATIONS
TechnicalSpecications
Standard Protocol
IEEE 802.1q standard
IEEE 802.1p QoS
IEEE802.1d Spanning Tree
IEEE802.3 1000 Base-T standard
IEEE802.3ab standard
Operation Mode Full/Half duplex mode
Connectors
UTP RJ-45
Fiber SC/ST/FC/LC
Bandwidth
RJ 45 Port 0°C~50°C (32°F ~ 122°F)
Optical Port 125Mbps
Emission / Safety FCCPart15,ClassA,RoHSandCEMark
Environmental
Parameters
Work Temperature 0°C~50°C (32°F ~ 122°F)
Storage Temperature -40°C~70°C (-40°F ~ 158°F)
Humidit 5%~90% non-condensing
Cable
UTP Cable Cat5e,6,6AUTPorSTPcable
Single-mode
8.3/125μm,8.7/125μm,9/125,μm,
10/125μm(themaxdistanceupto
20 -120km)
Multimode
50/125μm,62.5/125μm
(the max distance up to 2km or
5km)
Dimensions (mm) 95mm(L) x 71.5mm(W) x25.4mm(H)
Warranty 3 years
Mean Time Between
Failure
114,000 hours
TAA Compliant Yes
