HARDWARE DESCRIPTION
LED INDICATOR
LAMP
STATUS EXPLANATION
FX
On FX connection is good.
Blink FX data is transmitting.
Link/Act
On
Connection status display for electric link.
“ON”indicatesthatelectriclinkisincorrect
connection.
Blink
Activestatusdisplayofberlink
“Blink”indicatespacketgoesthroughTxend.
FDX
On Transceiver works in the full duplex mode.
O Transceiver works in the half duplex mode.
PWR On Power is on and normal.
100 On Lit when TP speed is 100Mbps.
1000
On FX speed is 1000Mbps.
O FX speed is 100Mbps.
