47
User Controls
Step 8: To open Internet Options, in IE web
browser, click Internet Options,
click the Connections tab and click
“LAN Settings...”.
Step 9: The Local Area Network (LAN)
Setting dialog box appears. In the
Proxy Server area, uncheck Use
a proxy server for your LAN, then
click “OK” button twice.
Step 10: Open your web browser and type
in the IP address in the URL and
press “Enter”.
Step 4: Select apply and press “Enter”
button to submit function or press
“menu” key to exit.
Step 5: To open Network Connections,
click Start, click Control Panel,
click Network and Internet
Connections, and then click
Network Connections. Click the
connection you want to configure,
and then, under Network Tasks
, click Change settings of this
connection.
Step 6: On the General tab, under
This connection uses the
following items, click Internet
Protocol (TCP/IP), and then click
“Properties.”
Step 7: Click Use the following IP
address, and type in as below:
1) IP address: 10.0.21.100
2) Subnet mask: 255.255.0.0
3) Default gateway: 10.0.0.254
To Next Page
