Appendices
b. Extended wide timing
Modes Resolution V. Frequency [Hz] H. Frequency [Hz]
WXGA
1280x720 60 44.8
1280x800 60 49.6
1366x768 60 47.7
1440x900 60 59.9
WSXGA+ 1680x1050 60 65.3
c. Video signal
Modes Resolution V. Frequency [Hz] H. Frequency [Hz]
480p 640x480 59.94/60 31.5
480i
720x480
(1440x480)
59.94(29.97) 15.7
576i
720x576
(1440x576)
50(25) 15.6
480p 720x480 59.94 31.5
576p 720x576 50 31.3
720p
1280x720 60 45.0
1280x720 50 37.5
1080i
1920x1080 60(30) 33.8
1920x1080 50(25) 28.1
1080p
1920x1080 23.98/24 27.0
1920x1080 60 67.5
1920x1080 50 56.3
d. HDMI 1.4a mandatory 3D timing- Video Signal
Modes Resolution V. Frequency [Hz] H. Frequency [Hz]
Frame
Packing
720p 50 31.5
720p 59.94/60 15.7
1080p 23.98/24 15.6
Side-by-
Side(Half)
1080i 50 31.5
1080i 59.94/60 31.3
Top and
Bottom
720p 50 45.0
720p 59.94/60 37.5
1080p 23.98/24 33.8
