SECTION 2
SPECIFIC SERVICE INSTRUCTIONS
2.1 MODEL NAME
Model name of printers
CX-D80*1 *2
Basic Structure
CX-D80SR : Single Side with Bend Remedy Unit
CX-D80D : Dual Side without Bend Remedy Unit
CX-D80DR : Dual Side with Bend Remedy Unit
CX-D80SRS : Single Side with Bend Remedy Unit (HS Model)
CX-D80DS : Dual Side without Bend Remedy Unit (HS Model)
2.2 Model name of built in option units. (Sell separately)
2.3 Life time of each parts
2.3.1 About thermal head
120,000 passes
(Approximately equivalent to 30,000 prints by using 4 colors, YMCK ink ribbon)
The life time of thermal head is defined as the time period when the heating element of the thermal head is broken caused by wearing
off the surface protective material.
2.3.2 Life time
• Durable parts
• Consumable parts
Life time to exchange is estimated based on enforcing daily maintenance.
• Life time for mechanism
100,000 cards printing for dual side printing with standard maintenance
• MTBF exclude life time parts is more than 12,000 hours
*1 *2 Convey Unit Bend Remedy Unit
SR/SRS Single Side Yes
D/DS Dual Side (With Flipper Unit) No
DR Dual Side (With Flipper Unit) Yes
Product name Description Remarks Appended goods
CF-7BR Bend Remedy Unit Remedy the bend of card after retransfer • Pressurized spring
ASSY
•Fixed screw
• Model label
CF-7MGS MG Encoding Unit (ISO) In accordance with ISO7810, 7811/2 MG stripe card
Only for dual side model (built in flip unit)
• Connection wire
•Fixed screw
• Model label
CF-7CRW Standard Contact IC R/W In accordance with ISO7816 IC card PC/SC, USB connect R/W
When it is installed to the printer, USB or Ethernet is selectable
• IC contact cable
• USB Cable
•Fixed screw
• Model label
CF-7CCS ISO Contact IC Case In accordance with ISO7816 IC card Coupled with the ISO MG
encoding unit.
• Option bracket
• GND wire
• Drive board
• Contact label
•Fixed screw
• Model label
Life time to exchange
1) Heater : 2,000 Hours
2) Thermal Head : 120,000 passes
3) Motor (DC motor ) : 100,000 panels
4) Heat Roller : 100,000 panels
5) Belt : 100,000 panels
Life time to exchange
1) Fan Filter : about 1 year
2) Cleaning Roller : about 1 year
