2.4 Name and functions of parts
2.4.1 Exterior
2.4.2 Internal mechanism
Communication Port for Laminator
Card Exit
Card stacker
Card Hopper
NG Card Exit
Host Interface
Display Panel
Space for input
out put connectors
Printer door
Power Switch
AC Inlet
Cooling Fan
Security Slot
Preliminary screw hole
Card stacker
Bend Remedy
Heat Roller
Retransfer heating roller
Card Convey
Section
Re-Transfer
Film Cassette
JOG Dial
Retransfer Film
Thermal head
RF-ID Antenna
JOG Dial
Ink Ribbon
Ink Cassette
Card hopper
Mag Encoder Unit
Contactless IC Encoder install space
Cleaning Roller
Card Convey Unit for
Single Sided or Dual Sided
IC Contact
