- 38 -
English
General:
Frequency Range 446.00625 - 446.09375 MHz (PMR)
433.07500 - 434.77500 MHz (LPD)
only WT77
Channels 8 (12.5 KHz spacing)
69 (25 KHz spacing)
only WT77
Modulation FM
Frequency Control P.L.L.
Power Supply 6.0V (4 x AAA 1.5V alkaline cells)
4.8V (4 x AAA 1.2V NiCd rechargable batteries)
Temperature Range -20/+55°C
Antenna Integrated
Jacks External Earset-Microphone, charging jack
Dimension 56 x 28 x 89 mm (W x D x H) incl. antenna
Weight 97gr (without batteries)
Transmitter:
RF Output Power PMR 500 mW e.r.p.
LPD 10 mW e.r.p
only WT77
Spurious
& Harmonics within the ETS 300 296 limits
Specifi cation
