Configuring Single Auditoriums and Multiple Auditoriums
Dolby
®
Digital Cinema System Manual Issue 0.92 (Preliminary) 33
3.6 Configuring Single Auditoriums and Multiple Auditoriums
This section shows you how to configure and test a Dolby Digital Cinema system. Because
single- and multiple-auditorium configurations are similar, this section covers both types
of setups.
The Dolby Digital Cinema system provides configuration software (Config script) with
semiautomatic default network settings for the DSS220, DSL100, CP650, CP750,
DMA8Plus, NA10, and digital cinema projectors, as described in Section 3.6.5. The Config
script automatically applies these defaults to the DSS220 and DSL100 using the default
screen number (1) for a single-auditorium installation and the specified screen number for
each screen in a multiple-auditorium installation (for example, 1, 2, 3, 4, 5, 6, 7, and 8 for
eight auditoriums). You must also set the defaults manually on the DMA8Plus, CP650,
CP750, NA10, and digital cinema projector using the setup software included with each of
these units. You can also use the Config script to override the default network settings and
enter the desired settings.
3.6.1 Configure the NA10, DMA8Plus, CP650, CP750
Enter the following default IP addresses, or enter your own settings (x = auditorium
number):
NA10 192.168.x.130
DMA8Plus 192.168.x.131
CP650 192.168.x.132
CP750 192.168.x.136
The default net mask for auditorium devices is 255.255.255.128.
Enter your settings using the setup software shipped with each of these units following the
instructions in the respective documentation.
Note: Your entries must match the corresponding settings in the Config script. For more
information, see Section 3.6.5.
