Dolmar MS-20 C - Page 3

Page
Pos.
MS-20 C
MS-22 C
Part No. Notes Description Specifications
1 1 1 374 101 000 SHAFT PIPE COMPLETE
1 2 1 374 150 040 SHAFT
1 3 1 374 300 400 GEAR CASE ASS'Y INC. 4,5,6,7,8-16
1 4 1 367 300 300 CUTTER SHAFT SET
1 5 1 381 250 030 BALL BEARING #609ZZ
1 6 1 367 006 999 BALL BEARING 626ZZ
1 7 1 367 010 993 BALL BEARING 6000DDU
1 8 1 381 850 010 RECEIVE WASHER
1 9 1 381 300 401 WASHER
1 10 1 381 150 800 OUTER SNAP RING
1 11 1 381 142 400 INNER SNAP RING
1 12 1 381 142 600 INNER SNAP RING
1 13 1 367 301 101 OIL BOLT M6X9
1 14 1 381 300 402 NUT M8
1 15 1 367 905 989 SOCKET HEAD BOLT M5X25
1 16 1 381 150 140 GASKET
1 17 1 367 905 990 SOCKET HEAD BOLT M5X12
1 18 1 381 700 200 HANGER ASS'Y INC. 19
1 19 1 374 905 985 SOCKET HEAD BOLT M5X14
1 91 1 381 005 994 TAPPING SCREW
1 92 1 374 500 700 CONTROL LEVER ASS'Y INC. 93,94
1 93 2 374 906 988 SOCKET HEAD BOLT M6X20
1 94 2 374 501 114 NUT
1 95 1 374 450 000 HANDLE (LOOP TYPE)
1 96 4 367 905 986 SOCKET HEAD BOLT M5X33
1 97 4 381 270 500 NUT M5
1 99 2 374 330 565 SCREW ASS'Y
1 100 1 374 300 403 AIR CLEANER COVER
1 101 1 374 300 401 AIR FILTER
1 102 1 374 300 402 AIR CLEANER HOUSING
1 103 1 374 600 500 CARBURETOR INC. 105,106,108-120
1 104 1 374 606 100 O RING
1 105 1 381 601 804 SWIVEL
1 106 2 388 600 803 PAN HEAD SCREW
1 108 1 381 600 512 RING
1 109 1 381 600 101 O RING
1 110 1 374 600 202 JET
1 111 1 381 600 103 PUMP GASKET
1 112 1 381 600 104 PUMP DIAPHRAGM
1 113 1 381 600 401 INLET SCREEN
1 114 1 374 604 613 PUMP BODY ASS'Y INC. 113
1 115 1 381 604 604 METERING DIAPHRAGM GASKET
1 116 2 381 600 525 METERING DIAPHRAGM ASS'Y
1 118 1 381 600 115 PRIMER PUMP
1 120 4 381 604 601 PUMP COVER SCREW
1 404 1 381 800 800 PROTECTOR ASS'Y
INC. PROTECTOR CLAMP & BOLT
MS-20 C
