18
Packing
Your DOLMAR chain saw comes delivered in a protective cardboard box to protect against shipping damage.
Cardboard is a basic raw material and is consequently reuseable or suitable for recycling (waste paper recycling).
Stroke volume cu. in (cm
3
)
3.7
(61) 3.7 (61)
Bore inch (mm) 1.85 (47) 1.85 (47)
Stroke inch (mm) 1.38 (35) 1.38 (35)
Max. power at speed hp / rpm 4.5 / 10.000 4.5 / 10.000
Max. torque at speed Nm / rpm 3,7 / 7.000 3,7 / 7.000
Idling speed / max. engine speed with bar and chain rpm 2.700 / 13.800 2.700 / 13.800
Clutch engagement speed rpm 5.100 5.100
Sound pressure level at the operator´s ear according to ISO 22868
dB(A) 105 105
Carburetor Type Membranecarburetor
Ignition system Type electronic
Spark plug Type NGK BPMR 7A
or spark plug Type --
Electrode gap inch (mm) .020 (0,5)
Fuel consumption at max. load per ISO 7293 kg/h 1,5 1,5
Specic consumption at max. load per ISO 7293 g/kWh 430 430
Fuel tank capacity oz (I) 27,0 (0,8)
Chain oil tank capacity oz (I) 16,2 (0,48)
Mixture ratio (fuel/two-stroke oil)
- when using DOLMAR High Performance oil 50 : 1
- when using other synthetic oils (oil quality must be JASO FC or ISO EGD) 50 : 1
Chain brake engages manually or in case of kickback
Sprocket pitch inch .325 or 3/8
Number of teeth Z 7
Chain type see the Extract from the spare-parts list
Pitch / gauge inch (mm) .325 / 0,050 (1,3), 0,058 (1,5)* or 3/8 / 0,050 (1,3)
Guide bar, length of a cut inch (cm) 18 (45) / 20 (50) / 21 (53) / 24 (60)
Guide-bar type see the Extract from the spare-parts list
Weight (fuel tank empty, without chain, guide bar and accessories) lbs 13.22 13.44
Technical data
PS-6100 PS-6100 H
WARNING:
This chain saw is capable of severe kickback that coult result in serious injury to the user. Do not operate this chain saw
unless you have extraordinary cutting needs and experience and specialized training for dealing with kickback. Chain saws
with signicantly reduced kickback potential are available.
* .325 / 0,058 Canada only.
