SPECIFICATIONS
RECOMMENDATIONS
1. Linear DC Power Supply
2. 22AWG shielded cable. It’s required to do “one-point”
ground (as shown in the diagram)
Input Voltage (at
Reader end)
DC10V~15V
Typical Read
range
> 5cm
Operating Current
160mA (max)
Maximum Cable
Length
150m
Operating
Temperature
-30ºC~70 ºC
Number pad
format
190
4 bits burst by default
Facility Code
