Dometic CFX3 Series User Manual

EN
CFX3 Technical data
37
12 Technical data
I
Test/certificates:
NOTE
The minimum temperature shown in „Cooling capacity“ cannot be
attained if the ambient temperature is above 32 °C (90 °F) for models
CFX3 35/45/55/55IM/100 or the ambient temperature is above
30 °C (86 °F) for models CFX3 75DZ/95DZ (set small –22 °C/large
+4 °C).
CFX3 35 CFX3 45 CFX3 55
Connection voltage: 12/24 Vg and 100 – 240 Vw
Rated current: 12 Vg: 7.5 A
24 Vg: 3.3 A
100 Vw: 0.94 A
240 Vw: 0.39 A
12 Vg: 8.2 A
24 Vg: 3.5 A
100 Vw: 0.96 A
240 Vw: 0.40 A
12 Vg: 8.7 A
24 Vg: 3.7 A
100 Vw: 0.98 A
240 Vw: 0.41 A
Cooling capacity: –22 °C to +10 °C (–8 °F to +50 °F)
Category: 1
Energy efficiency class: A++
Energy consumption: 81 kWh/annum 79 kWh/annum 83 kWh/annum
Gross volume: 36 l 46 l 55 l
Storage volume: 36 l 46 l 55 l
Climate class: N, T
Ambient temperature: +16 °C to +43 °C (+61 °F to +110 °F)
Noise emission: 44 dB(A) 47 dB(A)
USB charging port: 5 Vg, 2 A
Frequency range: WiFi: 2412 MHz – 2472MHz/2422 MHz – 2462MHz
Bluetooth/BLE: 2402 MHz – 2480 MHz
Frequency band (WiFi): 2.4 GHz
13
CFX3_OPM_EMEA.book Seite 37 Montag, 3. Februar 2020 5:41 17

Dometic CFX3 Series Specifications

General

Power Source	12/24V DC, 100-240V AC
Refrigerant	R134a
Product Description	Portable Refrigerator/Freezer
Temperature Range	-22°C to +10°C
Insulation	High-performance polyurethane foam
Digital Display	Yes
Connectivity	WiFi and Bluetooth
App Compatibility	Dometic CFX3 App
Color	Gray
Capacity	Varies by model (e.g., 35, 45, 55, 75, 95 liters)
Weight	Varies by model (refer to product specifications for specific weight)
Dimensions (W x H x D)	Varies by model (refer to product specifications for specific dimensions)
Certification	CE, RoHS
Warranty	3 years
Material	ExoFrame construction with fender frame protected edges
