Technical description CT4000
6
4.1 Description of the components
No. in fig. 1 Designation
1 Housing for cassette tank
2 Draining slider for toilet bowl
3 Toilet bowl, ceramic
4 Lid and seat, rotatable
5Console
6 Control and operating panel
7 CTLP, CTS only: Wall bracket
8 Cassette tank (capacity 19 l)
9 Service door (accessories)
