MasterFlush7640 Installation
9
4.2 Components
Please refer to complete parts list (printed separately) for more details.
5 Installation
I
No. in
fig. 1, page 3
Description
1 Vacuum breaker cover
2 Vacuum breaker
3 Macerator pump
4 Pump/base cover
5 Floor flange mounting hardware kit
6 Electrical wires
7 Floor flange seal
8 Water valve
9 Flush pedal
10 Toilet base
11 Toilet bowl
12 Toilet seat
– Remote mounting hardware kit
NOTE
Be sure foot pedal, when pressed, touches same flat surface
on which toilet is installed.
Be sure to follow recommended installation requirements
(chapter “Minimum installation requirements” on page 21).
The toilet is not intended for installation in a shower.
