PI8022, PI8023, MO9722 Installing the device
17
1. Connect the pipes as shown (fig. 9).
The connection of the gas pipe to the appliance (1/4 BSPT female) must be
made with a rigid metal pipe. The pipe work and fittings shall be free from
defects and of an approved type.
Recommended torque: 12 – 15 Nm.
2. Open the gas supply.
!
3. Check all connections for leaks with leak spray or soapy water.
There are no leaks if no bubbles form.
WARNING! Beware of injury!
Never check for leaks with an open flame or near sources of ignition.
