MSI924M Connecting the inverter
15
9.2 Connecting the inverter to the battery
I
➤ Set the main switch (fig. 5 1, page 4) to “OFF”.
➤ Loosen the screw (fig. 6 1, page 5) from the red positive terminal (fig. 6 2,
page 5).
➤ Push the cable lug (fig. 6 2, page 5) of the positive cable into the red positive
terminal and fasten it with the screw.
➤ Connect the negative cable to the black negative terminal (fig. 6 4, page 5).
➤ Lay the positive cable from the inverter to the positive terminal of the vehicle bat-
tery and connect it.
➤ Lay the negative cable from the inverter to the negative terminal of the vehicle
battery and connect it.
➤ Connect the earth terminal to the vehicle chassis.
9.3 Connecting the MCR9M remote control (accessory)
A
➤ Connect the remote control (accessory) to the remote port (fig. 4 2, page 4).
NOTE
Tighten the nuts and bolts to a maximum torque of 12 – 13 Nm. Loose
connections may cause overheating.
NOTICE!
• Only plug in the connection to the remote control in the remote port.
The device can be damaged by connecting it incorrectly.
• Ensure that the remote control and inverter are supplied with the
same input voltage.
• Follow the instruction manual of the remote control.
