Technical data MSI924M
22
15 Technical data
I
NOTE
In the event of thermal overloading, the inverter reacts by reducing the
power for temperatures of 40 °C and above.
If the temperature exceeds 60 °C, the inverter switches off.
Dometic MSI924M
Ref. no.: 9600000345
Rated input voltage: 24 V g
Output power
at 25 °C for 10 min:
700 W
Peak output power: 1500 W
Output voltage range: 180 – 220 Vw pure sine wave (THD < 3 %)
Output frequency: 50 or 60 Hz
Idle current consumption: 1.0 A
Standby current consumption: 0.3 A
Input voltage range: 21 V – 32 V
Efficiency up to: 91 %
Ambient temperature for
operation:
–20 °C to 40 °C
40 °C to 60 °C (reduced power)
Ambient temperature for storage –30 °C to +70 °C
Dimensions W x D x H: 197.5 x 94.3 x 291 mm, see fig. a, page 6
Weight: 4 kg
