SinePower Technical data
23
15 Technical data
The following technical data applies to all inverters:
Output voltage: 230/240 Vw ± 3 %, pure sine wave
(THD < 3 %)
Output frequency: 50/60 Hz ± 0,3 Hz
Heat dissipation: temperature and load controlled fan
Ambient temperature at operation: –20 °C to +60 °C
Ambient temperature for storage: –30 °C to +70 °C
Power control: ≥40 °C
Bypass relay: 16 A/250 Vw
Bypass switching with voltage
synchronisation:
<20 ms
Air humidity: 0 – 95 %, non-condensing
Testing/certification:
13
DSP1300T-3500T--IO-16s.book Seite 23 Freitag, 1. Dezember 2017 8:54 08
