Connecting the inverter SinePower
14
9 Connecting the inverter
9.1 General instructions
!
• When installed in vehicles or boats, the inverter must be connected to the chassis
or earth.
• When setting up a socket distribution circuit (mains setup), comply with the
applicable regulations.
• Only use copper cables.
• Keep the cables as short as possible (< 1 m).
• For grounding use a cable with a minimum cross section of 4 mm².
• Keep to the specified cable cross section and fit a cable fuse (fig. 6 1) as close
to the battery as possible on the positive cable (see the table).
WARNING!
• The inverter may only be connected by a qualified workshop. The
following information is intended for technicians who are familiar
with the guidelines and safety precautions to be applied.
• Never use the inverter on vehicles where the positive terminal of the
battery is connected to the chassis.
• If you do not fit a fuse to the positive cable, the cables can over-
load, which might result in a fire.
Device
Required cable
cross section
Cable fuse
DSP1312T 35 mm² 200 A
DSP1324T 25 mm² 150 A
DSP1812T 50 mm² 250 A
DSP1824T 25 mm² 150 A
DSP2312T 70 mm² 300 A
DSP2324T 35 mm² 200 A
DSP3512T 2 x 50 mm² 2 x 250 A
DSP3524T 50 mm² 250 A
DSP1300T-3500T--IO-16s.book Seite 14 Freitag, 1. Dezember 2017 8:54 08
