Fitting the inverter SinePower
12
7.2 Connections
I
8 Fitting the inverter
I
8.1 Tools required
For the electrical connection you will need the following tools:
• Crimping tool
• 3 multi-coloured, flexible connection cables. Determine the necessary thickness
from the table in chapter “Connecting the inverter” on page 14.
• Cable lugs and conductor sleeves
For fastening you will require the following tools:
• Machine bolts (M4) with washers and self-locking nuts or
• self-tapping screws or wood screws.
NOTE
The version for continental Europe is depicted.
No. in
fig. 2
Description
5 AC input (DSP35xxT: PG fitting)
6 AC output (DSP35xxT: PG fitting)
7 Ground terminal (Earthing on the vehicle bodywork)
8 Positive terminal
9 Negative terminal
10 CI/LIN BUS connections (LINA)
11 Remote control connection (LINB)
12 Connection of remote switch
13 Fan (backside)
NOTE
Before fitting the inverter, you should connect all cables because all
connections are freely accessible.
DSP1300T-3500T--IO-16s.book Seite 12 Freitag, 1. Dezember 2017 8:54 08
