Dometic Smart D User Manual

EN
Dometic Smart D Connecting and installing Dometic Smart D
45
5 Towing-
Connector
Connection for motor home rear vehicle lights (only for
motor homes)
(cable cross section up to 2.5 mm²)
Pin1: Left-hand direction indicator light
Pin2: Rear fog light
Pin3: Earth
Pin4: Right-hand direction indicator light
Pin5: Right-hand traffic lights
Pin6: Stop lights
Pin7: Left-hand traffic lights
Pin8: Reversing light
Note: Connect D+ to Pin5 (right-hand traffic lights), if
you want to charge the supply battery via the vehicle
light system. In the event of a discharged battery, the
relevant relay is switched to charging this battery
through the light system as a result of doing this.
6 RearRamp Connection for the rear vehicle lights of the towing vehi-
cle (only if a caravan is attached)
(cable cross section up to 2.5 mm²)
Pin1: Left-hand direction indicator light
Pin2: Rear fog light
Pin3: Earth
Pin4: Right-hand direction indicator light
Pin5: Right-hand traffic lights
Pin6: Stop lights
Pin7: Left-hand traffic lights
Pin8: Reversing light
7 BUS Connection to the CI Bus
(cable cross section 0.5–1mm²)
No. in
fig. 7,
page 6
Description Explanation

Dometic Smart D Specifications
