Dometic Smart D Operating Dometic Smart D
61
Calibration menu for analogue filling level sensors (float)
If the filling levels displayed do not correspond with the actual filling levels,
you can calibrate the display (fig. h, page 10).
To do this, proceed as follows:
➤ Empty the tank whose filling level display you want to calibrate:
– FW: Fresh water tank 1
– FW2: Fresh water tank 2
– GW: Waste water tank
➤ Press the “Min” button on the relevant tank.
✓ The sensor reads the filling level and transfers the value to the control
panel.
➤ Fill the tank up to the maximum.
➤ Press the “Max” button on the relevant tank.
✓ The sensor reads the filling level and transfers the value to the control
panel.
Signal menu
The signal menu (fig. i , page 10) displays the states of the input and output
signals on the connected I/O cards. When the signal's display lights up
green, this signal is activated.
I
Using the “Inputs” and “Outputs” buttons, you can alternate between the dis-
play of the inputs and output signals.
Alarm menu
The alarm menu (fig. j, page 11) is automatically displayed when an alarm
occurs. An alarm occurs if the battery voltage of the consumer battery is
exceeded or falls short.
You can cancel the alarm list by pressing the button “Ack All” (Acknowledge
all)
NOTE
The signal menu can display different signals depending on your
installation. Please refer to the supplementary sheet enclosed for
this.
