TEC29 EV AUS Connecting the electrical power to the generator
29
Control panel (fig. f, page 10)
9.3 Connecting 230 V
A
➤ Guide the 230 V connection cable through the cable passage in the
housing and connect it to the 230 V terminals (fig. f 7, page 10).
➤ Connect the earth cable to the earth connection on (fig. f 8, page 10).
Item Description
1 Main switch
2 Main fuse
3 Battery charger fuse
4 Digital control panel connection
5 Connector for service purposes
6 Battery positive terminal
7 230 V connection
8Earth
9 Float connection (petrol tank)
10 No connection required
NOTICE!
Connect a relay or a change over switch to the vehicle’s
electrical system so that the generator is not damaged when
the external mains is connected (according to AS3001
regulation).
The neutral conductor is internally linked to the PE conductor.
To protect against automatic shutdown, make sure that a
safety switch (RCD switch, 30 mA) and an in all-pole overcur-
rent protection (e.g. circuit breaker, 12 A) are installed
(according to AS3001 regulation) between the generator and
the change over switch.
