Connecting the electrical power to the generator TEC29 EV AUS
30
9.4 Connecting the starter battery
A
➤ Connect the positive terminal of the battery to the positive battery terminal
connection using a cable with a cross-section of 10 mm² for a length of
< 6 m or 16 mm² for a length of > 6 m (fig. f 6, page 10).
➤ Fit a 100 A fuse in the positive cable near the positive terminal of the
starter battery to protect the generator’s electrical system.
➤ Connect the negative terminal of the battery using a cable with a suitable
cross-section (see above) via the insert of the generator (fig. g 1,
page 10).
➤ Connect the earth connection on the generator to the vehicle chassis.
Remove any paint or rust from the chassis if necessary to ensure good
contact.
➤ Protect the connections by applying lubrication.
NOTICE!
The starter battery must have 12 V and a capacity of at least
60 Ah. Make sure that the battery is fully charged.
