TEC29 EV AUS Connecting the electrical power to the generator
31
9.5 Configuring the automatic mode
I
In automatic mode, the generator switches on automatically and charges the
battery if the voltage of the connected battery is too low.
The generator switches off automatically once the battery has been fully
charged.
The circuit diagram for the automatic mode can be found in fig. h, page 11.
➤ Connect the black wire to a suitable switch and connect the switch to the
ignition.
➤ Connect the white wire to a suitable switch.
9.6 Connecting the digital control panel
➤ Connect the provided extension cable to the digital control panel
(fig. d 2, page 8) and the generator control panel (fig. f 4, page 10).
Connecting the autostart wiring
➤ Connect the provided wiring to the digital control panel (fig. d 1, page 8).
➤ To enable the autostart function, connect the black wiring as shown in
fig. h, page 11.
➤ To enable the remote ON/OFF function, connect the white wiring as
described in fig. h, page 11.
9.7 Connecting the float
➤ Connect the float from the tank to the float connection (fig. f 9,
page 10).
NOTE
You can only use automatic mode:
– if the vehicle is stationary and the ignition is switched off
To shorten charging times, an additional charging unit with at
least 20 A can be installed between the generator and discon-
nector switch, especially if batteries with a capacity of more
than 60 Ah are used. In this case remove the fuse (fig. f 3,
page 10) from the internal control panel.
