Domino G20I Guide

EPT052026 Issue 1 February 2019 (11)
COMMUNICATION PROTOCOL TABLES
There are two protocol tables. The list of protocols for PC to printer communication begins on this
page. The list of protocols for PLC to printer communication begins on page 23.
PC to Printer
The table below lists RS485 communication commands for PC to printer connection.
Table 1: PC to Printer
Operation Command Parameter Examples UDP Port
Start/Stop Print
^1R01CS
*x\0 *x=1: Start print
*x=0: Stop print
^1R01CS1\0 = Start printing.
^1R01CS0\0 = Stop printing.
8080
Set Print Speed
(inches/min)
^1S01CS*
x*y\0
*x=1: Use encoder
*x=0: Don’t use encoder
*y: Print speed in inches
(mandatory 5 characters).
^1S01CS101200\0 = Use
encoder.
^1S01CS001200\0 = Do not
use encoder. Set print speed to
01200 inches/min.
8080
Set Resolution ^1O01CS*x\0 *x=7: 300x100 dpi
*x=6: 300x150 dpi
*x=5: 300x200 dpi
^1O01CS7\0 = Set resolution to
300x100 dpi
^1O01CS6\0 = Set resolution to
300x150 dpi
^1O01CS5\0 = Set resolution to
300x200 dpi
8080
Set Density ^1B01CS*x\0 *x=1: Set density to 1
*x=2: Set density to 2
*x=3: Set density to 3
*x=4: Set density to 4
*x=5: Set density to 5
^1B01CS1\0 = Set density to 1
^1B01CS1\0 = Set density to 2
^1B01CS1\0 = Set density to 3
^1B01CS1\0 = Set density to 4
^1B01CS1\0 = Set density to 5
8080
Set Print Side ^1Q01CS*x*y*z\
0
*x=0: Set print side mode
to manual.
*x=1: Set print side mode
to auto.
*y=0: Set cartridge side to
even.
*y=1: Set cartridge side to
odd.
*z: Number of prints per
side before switching.
This value is passed if set
to manual mode
(mandatory 5 characters).
^1Q01CS1001000\0 = Set print
side mode to Auto. After 1000
prints the print side will change.
^1Q01CS0100000\0 = Set print
side mode to Manual and print
side to Odd.
