Installation, Operation and Maintenance manual
16
Downflo
®
Evolution
back-flap valve
OUTSIDE
INSIDE
CAP
outlet
DAP
inlet
dust
collector
blow-o
channel
roof
Figure 3: Inside installation
Installation and assembly
Anchor the dust collector to the foundations.
If any of the following equipment is ordered and mounted please follow the
respective instructions.
