Installation, Operation and Maintenance manual
18
Downflo
®
Evolution
detail A detail B
detail Ddetail C
detail E
yoke
filter cartridge panel
thread-
forming
screw
gasket
washer
flat washer
flat
washer
thread-
forming screw
hex nut hex jam nut
clean air plenum
sealant detail
outlet cover
yoke, see
detail A
access
cover
filter
cartridge
Figure 5: Yoke, venturi and filter installation
