DEVICE WITH CALL BUTTON
1) Front panel
2) HDTV Video
3) Security screws
4) Light Sensor
For night-vision mode
5) Bluetooth transceiver
6) Speaker
7) Microphone
8) 4D Motion sensor
9) Illuminated call button with nameplate
10) Diagnostic-LED
Lights up a few seconds after
connecting the device to power
11) Main Electrical Unit
12) Screw connection terminal
13) Gasket
14) Housing with wall-mounting bracket
The flush-mounted model may differ optically.
Front Inside
2
1
4
5
3
7
8
9
6
1x Drilling template 1x Waterproof A4 laser
printer paper for labelling
name plates
1x Power supply unit (mains adaptor)
with four country-specific adaptors
1x Screw connection
terminal plug
1x RJ45 Adapter
1x Quickstart guide
with Digital Passport
1x Installation manual1x Main Electrical Unit
with call button(s)
and front panel
1x Back-housing with
wall-mounting bracket
10
11
12
13
14
* The sketches in this manual may differ from the purchased model.
COMPONENTS*
WIFI
Small parts
To Next Page
