DoorHan CV01 User Manual

1. GENERAL INFORMATION
CV01 control unit is designed for remote and stationary control of:
 electrical locks;
 sectional door operators;
 electric drives for sunshades, window shutters and rolling doors;
 lighting.
It can also be used to provide effective operation of other companies‘ drives with DoorHan remote controls and to automate
various devices.
2. SPECIFICATIONS
Table 1. Control unit technical characteristics
Parameters Value
Supply voltage 220 V, 50–60 Hz
Maximum rated current, not more than 4 A
Maximum rated voltage 220 V ± 10 %
Fuse breaking capacity 4 A
Number of operated drives 1
Operating temperature -40…+70 °C
Electrical protection class according to GOST 27570 II
IP code (waterproof and dustproof ratings) IP 54
Table 2. State of the rolling shutter when operated with control unit
Type of control
State of the rolling shutter
open closed is opening is closing
Remote control, key-switch
starts to close starts to open stops stops
Press the “Open” button – starts to open – stops
Press the “Close” button starts to close – stops –
Press and hold the “Open” button
for more than 5 sec
– starts to open
opens till the button is
released
starts to open
Press and hold the “Close” but-
ton for more than 5 sec
starts to close – starts to close
closes till the button is
released
Multi-channel remote control
Press the “Open” button starts to close starts to open – starts to open
Press the “Close” button – – starts to close –
Press the “Stop” button starts to close – stops stops
3. INSTALLATION
1. Remove the control unit from the packaging. Unscrew the four screws located on the device casing, and take off the cover.
2. Carefully unscrew the two mounting screws on the control board and remove it from the casing.
3. Make the electrical connections in accordance with fig. 1, 2, 3.
4. Carefully attach the control board into the casing using the two mounting screws and close the cover.
5. Ensure maximum protection of the device from dust and moisture during installation. Use cable entries to connect mounting
wires to the control board.
WARNING!
 Ensure minimum distance of 50 cm between the device and the ground level.
 Minimum distance between neighbouring control units should be 20 cm at least.
 Take the receiver antenna out of the casing to ensure proper signal reception.
