20
Item
Element
Criterion
Actions
Protection
devices
Signal lamp
Functionality, no
damage
External inspection for defects
of the body.
Check the integrity of the
filament lamp, cap and lamp
holder.
Check the connecting
contacts to the drive control
board.
Check the integrity of the
wiring.
Replacement criteria: serious
mechanical damage, burned
lamp board
Open wicket-door
sensor
External inspection for defects
of the terminal box and
magnet.
Check the connecting
contacts to the drive control
board.
Check the integrity of the
spiral cable and wiring in
general.
Replacement criteria: serious
mechanical damage
Traffic signal
External inspection for defects
of the body and LEDs.
Check the connecting
contacts to the drive control
board and traffic signal control
board.
Check the LED indication.
Check the integrity of the
spiral cable and wiring in
general.
Replacement criteria: serious
mechanical damage, burned
traffic signal control board
Stop button
External inspection for defects
of the body and buttons.
Check the connecting
contacts to the drive control
board.
Check the integrity of the
wiring.
Replacement criteria: serious
mechanical damage
