9.3.33. Alternator
•
Install the alternator mounting bracket.
•
Install the alternator with fixing bolts to
the mounting bracket.
9.3.34. Fuel filter
•
Assemble the fuel filter with the intake
manifold.
•
Assemble the fuel feed hose according
to the direction of an arrow impressed on
the fuel filter head so that fuel can be fed
in the sequence of FUEL FEED PUMP
FUEL FILTER FUEL INJECTION
PUMP.
9.3.35. Injection nozzle
•
Install the dust seal with its round portion
facing downward.
•
Mount a seal ring on the seal ring seating
surface of the cylinder head and
assemble nozzle holder assembly with
the nozzle pipe installing direction facing
outward.
•
Be sure to follow the specified torque.
- 118 -
