Transmission Inching Control
Pedal
Typical Example
Inching Control Pedal - Pushing down on
the inching pedal, modulates the hydraulic
pressure to the clutch packs, permitting
disc slippage.
Further pushing on the pedal completely relieves
clutch pack pressure and applies the service brakes
to stop and hold the lift truck.
NOTE: The purpose of the inching control pedal is
to provide precise inching control at slow
travel speed, with high engine rpm. This is
used for fast hydraulic lift during load
approach, pickup or positioning.
Service Foot Brake Pedal
Typical Example
Push DOWN on the brake pedal to slow or
stop the lift truck.
RELEASE the brake pedal to allow the lift
truck to move.
Accelerator Pedal
Typical Example
