General Section
35
Specifications
CHARACTERISTICS
2 Speed (TIER-IV 55KW)
1 Manufacturer DOOSAN DOOSAN
2 MODEL D60S-7 D70S-7
3 Capacity at rated load center kg 6000 7000
4 Load center distance mm
600
600
5 Power type electric, diesel, gasoline, LPG diesel diesel
6 Operator type stand-on, rider-seated rider-seated rider-seated
7 Tire type c=cushion, p=pneumatic P p
8 Wheels(x=driven) number, front/rear 4/2 4/2
DIMENSIONS
9 Lift with STD
maximum fork height with rated
load
mm 3000 3000
10 two stage mast free lift mm 205 205
13 Forks
thickness x width x length mm 60x180x1200 60x180x1200
fork spacing(minimum x maximum) mm 410x2032 410x2032
14 Tilt of mast forward / backward deg 15/10 15/10
15
Overall
dimensions
length to face of forks mm 3618 3697
16 width mm 2156 2156
17 mast lowered height mm 2500 2500
18 mast extended height mm 4340 4340
19 overhead guard height (Cabin) mm 2468(2535) 2468(2535)
20 seat height mm 1455 1455
21 Turning radius (minimum outside) mm 3380 3430
22 Load moment constant mm 632 632
23 90 stacking aisle add load length and clearance mm 3958 4000
23a 90 intersecting aisle mm 3020 3058
PERFORMANCE
24
Speed
travel, loaded/unloaded km/h 23.0/25.0 22.6/24.6
25 lift, loaded/unloaded mm/s 400/430 380/430
26 lowering, loaded/unloaded mm/s 500/450 500/450
28 Drawbar pull at 1.6 km/h, loaded kg 4668 4630
30 Gradeability at 1.6 km/h, loaded % (deg) 33.1(18.3) 28.8(16.1)
WEIGHT
32 Total weight unloaded kg 8950 9630
33 Axle load with loaded, front/rear kg 13285/1655 14655/1975
34 without loaded, front/rear kg 4050/4890 3900/5730
CHASSIS
35
Tires
number of front/rear 4/2 4/2
36 size, front 8.25x15-14PR 8.25x15-14PR
37 size, rear 8.25x15-14PR 8.25x15-14PR
38 Wheel base mm 2250 2300
39 Tread width front/rear mm 1584/1550 1584/1550
40
Ground clearance
loaded, at the lowest point mm 196 196
41 loaded, at center of wheelbase mm 225 225
42
Brakes
service brake foot/hydraulic foot/hydraulic
43 parking brake hand/mechanical hand/mechanical
DRIVE
45 Battery voltage/capacity v/ah 24/75 24/75
49
Engine
manufacturer/model DI/D34NAP DI/D34NAP
50 rated output (at rpm) KW/rpm
55/2300
(74.8ps)
55/2300
(74.8ps)
51 Max. torque N-m/rpm
330/1400
(33.6Kgf.m)
330/1400
(33.6Kgf.m)
52 cycle/cylinders/displacement cc 4/4/3409 4/4/3409
55
Transmission
type Power Shift Power Shift
56 no. speeds forward/reverse 2/2 2/2
