General Section
36
Specifications
CHARACTERISTICS 2 Speed (TIER-3 PSI 4.3L)
1 Manufacturer
DOOSAN DOOSAN
1
2 MODEL G60S-7 G70S-7 2
3 Capacity at rated load center kg 6000 7000 3
4 Load center distance mm 600 600 4
5 Power type electric,diesel,gasoline,LPG LPG LPG 5
6 Operator type stand-on, rider-seated rider-seated rider-seated 6
7 Tire type c=cushion, p=pneumatic p p 7
8 Wheels(x=driven) number, front/rear 4/2 4/2 8
DIMENSIONS
9 Lift with STD maximum fork height with rated load mm 3000 3000 9
10 two stage mast free lift mm 205 205 10
13 Forks
thickness x width x length mm
60x180x1200 60x180x1200
13
fork spacing(minimum x maximum) mm 410x2032 410x2032
14 Tilt of mast forward / backward deg 15/10 15/10 14
15 Overall length to face of forks mm 3618 3697 15
16 dimensions width mm 2156 2156 16
17 mast lowered height mm 2500 2500 17
18 mast extended height mm 4340 4340 18
19 overhead guard height(Cabin) mm 2468(2535) 2468(2535) 19
20 seat height mm 1455 1455 20
21 Turning radius (minimum outside) mm 3380 3430 21
22 Load moment constant mm 632 632 22
23 90 stacking aisle add load length and clearance mm 3958 4000 23
23a 90 intersecting aisle mm 3020 3058 23a
PERFORMANCE
24
Speed
travel, loaded/unloaded km/h 22.6/23.7 22.5/23.4 24
25 lift, loaded/unloaded mm/s 380/410 380/410 25
26 lowering, loaded/unloaded mm/s 490/460 490/460 26
28 Drawbar pull
stall, loaded kg
5489 5477
28
at 1.6 km/h, loaded kg 4262 4236
30 Gradeability at 1.6 km/h, loaded % 30 26.5 30
WEIGHT
32 Total weight unloaded kg 8745 9425 32
33 Axle load with loaded, front/rear kg 13250/1495 14585/1840 33
34 without loaded, front/rear kg 4040/4705 3835/5590 34
CHASSIS
35
Tires
number of front/rear 4/2 4/2 35
36 size, front 8.25x15-14PR 8.25x15-14PR 36
37 size, rear 8.25x15-14PR 8.25x15-14PR 37
38 Wheel base mm 2300 2300 38
39 Tread width front/rear mm 1584/1550 1584/1550 39
40
Ground clearance
loaded, at the lowest point mm 176 176 40
41 loaded, at center of wheelbase mm 205 205 41
42
Brakes
service brake foot/hydraulic foot/hydraulic 42
43 parking brake hand/mechanical hand/mechanical 43
DRIVE
45 Battery voltage/capacity v/ah 12/75 12/75 45
49
Engine
manufacturer/model PSI4.3L(TIER-3) PSI4.3L(TIER-3) 49
50 rated output (at rpm) KW(hp)/rpm 70(93.8)/2500 70(93.8)/2500 50
51 max. torque N-m(lb-ft)/rpm 283.9(209.4)/1800 283.9(209.4)/1800 51
52 cycle/cylinders/displacement cc 4/6/4294 4/6/4294 52
55
Transmission
type Power Shift Power Shift 55
56 no. speeds forward/reverse 2/2 2/2 56
