- 6 -
Specifications
CAUTION
* The droop is based on the 4,000 Hz speed detection frequency from no load to full load, as
well as changes of 1 A in the actuator current. When the speed sensor signal is high, the
amount of droop decreases, and when the amount of change in the actuator is large, the
amount of droop changes significantly. For details about droop operation, refer to the
description of droop.
** Protects against back voltage using a diode. A 15 A fuse must be installed on the battery
anode.
*** There is a protective device which cuts off current flowing to the actuator in the event of a
short circuit. Once this short circuit is removed, the device automatically returns to normal.
Item Details Specifications
Performance
Simultaneous Operation /
Relative Normal Stability
±0.25 % or less
Speed Range / Governor 1 K ~ 7.5 KHz continuously
Speed deviation based on changes in temp. Max. ±1%
Idle Adjustment (Clockwise) 1,200 Hz or less
Idle Adjustment (Counterclockwise) 4,100 Hz or less
Droop Range Adjustable between 1 ~ 5%
Max. Droop Adjustment
(With Terminals K-L Connected)
Fluctuation of 875 ±75 Hz / 1.0 A
Min. Droop Adjustment
(with Terminals K-L Connected)
Fluctuation of 15 ±6 Hz / 1.0 A
Speed Trim Range ±200 Hz
Remote Variable Speed Range 500 ~ 7.5 Hz
Terminal
Sensitivity
J 100±15Hz / Volt @ 5.0K
L 735 ±60 Hz / Volt @ 65 K
N 148±10Hz / Vo1t @ 1Meg
P 10 V DC supply @ 20 ma.
Speed Switch Adjustment Range 1,000 ~ 10,000 Hz
Environmental
Conditions
Ambient Operating Temperature Range -40 ~ 85°C
Relative Humidity Up to 95 %
Surface Treatment Corrosion resistance
Input Power
Supply
12 or 24V DC (instantaneous and back
voltage protection) *
Polarity " - " ground
Power Consumption 50 mA of continuous current to actuator
Actuator Current at 25°C (Inductive Load) Continuous min. 2.5 A, max. 10 A **
Speed Sensor Input Voltage 0.5 ~ 120V
Speed Switch Relay Contact
(N.O. and N.C.)
10 A
Reliability
Vibrations 1 G @ 20 ~ 100 Hz
Testing 100 % functionality test
Type
Dimensions Refer to outside view feature
Weight 820 g
Installation Installed vertically
To Next Page
