3. Engine configuration
(1) Engine type configuration
Users can store control setting information depending on types of the engines in the internal memory
of the controller. If you select your engine type, applicable parameters will be automatically configured
accordingly. This feature is available for 16 different types of engines.
Designated parameters by engine type (Configuration values by engine type)
No. Menu Name Run rpm Over Speed
Gear
Teeth
Starting
Fuel
PID Value
1
DB58 1,500 rpm
(50 Hz) 129T
1,500 rpm 1,725 rpm 129 65%
Optimal
Value
2
DB58 1,800 rpm
(60 Hz) 129T
1,800 rpm 2,070 rpm 129 65%
Optimal
Value
3
DE08 1,500 rpm
(50 Hz) 102T
1,500 rpm 1,725 rpm 102 65%
Optimal
Value
4
DE08 1,800 rpm
(60 Hz) 102T
1,800 rpm 2,070 rpm 102 65%
Optimal
Value
5
DE08 1,500 rpm
(50 Hz) 140T
1,500 rpm 1,725 rpm 140 65%
Optimal
Value
6
DE08 1,800 rpm
(60 Hz) 140T
1,800 rpm 2,070 rpm 140 65%
Optimal
Value
7
DE08 1,500 rpm
(50 Hz) 146T
1,500 rpm 1,725 rpm 146 65%
Optimal
Value
8
DE08 1,800 rpm
(60 Hz) 146T
1,800 rpm 2,070 rpm 146 65%
Optimal
Value
9
DL11 1,500 rpm
(50 Hz) 152T
1,500 rpm 1,725 rpm 152 65%
Optimal
Value
10
DL11 1,800 rpm
(60 Hz) 152T
1,800 rpm 2,070 rpm 152 65%
Optimal
Value
11
DV15 1,500
rpm
(50 Hz) 160T
1,500 rpm 1,725 rpm 160 65%
Optimal
Value
12
DV15 1,800 rpm
(60 Hz) 160T
1,800 rpm 2,070 rpm 160 65%
Optimal
Value
13
DV18 1,500 rpm
(50 Hz) 160T
1,500 rpm 1,725 rpm 160 65%
Optimal
Value
14
DV18 1,800 rpm
(60 Hz) 160T
1,800 rpm 2,070 rpm 160 65%
Optimal
Value
15
DV22 1,500 rpm
(50 Hz) 160T
1,500 rpm 1,725 rpm 160 65%
Optimal
Value
16
DV22 1,800 rpm
(60 Hz) 160T
1,800 rpm 2,070 rpm 160 65%
Optimal
Value
