4. Regular inspection
48
DV2213205B
CAUTION
To keep the optimum performance of the air cooler,
clean it regularly.
Air/air intercooler
with downstream
radiator
(Combined radiator)
Cooling air
Hot charge air
from compressor
Recooled charge air
to intake pipe (max. 50 C)
