Maintenance - 134 -
 Truck
Terminal No.
Terminal
Symbol
Wire Description
Connector
Pin no.
Signal Name
P16 B AEXF 0.85 L/Y ECU J1-C15 AN27_ECT
P20
1AEXF
0.85 L/ R ECU J1-B21 LSU1_UN
2AEXF
0.85 L/ R ECU J1-B15 LSU1_IA
4AEXF
0.85 L/ R ECU J1-B20 LSO1_LSUH2
5AEXF
0.85 L/ R ECU J1-B1 LSU1_VM
6AEXF
0.85 L/ R ECU J1-B14 LSU1_IP
P21
AAEXF
0.85 WECU J1-A31 CAM -
B AEXF
0.85 B ECU J1-A20 CAM +
P28 1 AEXF
0.85 Y ECU J1-A21 AN7_PTP
P29
1 AEXF
0.85 Y ECU J1-A29 AN4_MAP
3 AEXF
0.85 Or ECU J1-C7 AN28_MAT
P31 B AEXF
0.85 L/W ECU J2-B21 WGCV
P32
6AEXF
0.85 GECU J1-A14 AN1_TPS
12 AEXF
0.85 L/B ECU J2-B5 EST14
P36
AEXF
1.25 BECU J2-A16
AEXF
1.25 BECU J2-A24
AEXF
1.25 BECU J2-A15
AEXF
1.25 B ECU J2-B9
P40
9 AEXF
0.85 Y ECU J1-A30 ANO5_R. HUMIDITY
10 AEXF
0.85 Or ECU J1-A27 AN16_RH-TEMP/NGTT
P50 C AEXF
0.85 L ECU J1-A16 AN10_NGTP
P62
1 AEXF
0.85 Br P40 CONN 1
2 AEXF
0.85 Br P40 CONN 3
3 AEXF
0.85 Br P40 CONN 5
5 AEXF
0.85 Y ECU J2-A12 EST1_RESET
6 AEXF
0.85 Y ECU J2-A14 EST3_TRIGGER
7 AEXF
0.85 Y ECU J1-A9 DG4M_IMON
8 AEXF
0.85 Y ECU J2-A22 EST_RTN_SIGNAL RTN
10 AEXF
0.85 Br P40 CONN 6
11 AEXF
0.85 Br P40 CONN 4
12 AEXF
0.85 Br P40 CONN 2
P63
1AEXF
0.85 W ECU J2-A1 INJ 1
2AEXF
0.85 W ECU J2-A3 INJ 2
3AEXF
0.85 W ECU J2-A7 INJ 3
4AEXF
0.85 W ECU J2-A6 INJ 4
5AEXF
0.85 W ECU J2-A8 INJ 5
6AEXF
0.85 W ECU J2-A5 INJ 6
7AEXF
0.85 W ECU J2-A2 INJ 7
8AEXF
0.85 W ECU J2-A4 INJ 8
P63
12 AEXF
0.85 L ECU J1-A25 AN9_NGP
14 AEXF
0.85 Y ECU J1-A10 AN13_NGT
